An outranking model has three tuning surfaces: the
thresholds of each criterion, the
weights between criteria, and the number of
clusters k. A good analysis checks that its
conclusions are not an artefact of a single arbitrary choice. This
vignette shows how, using illustrative_log.
traces <- as_traces(illustrative_log, "case_id", "activity", "timestamp")
criteria <- function(activity_sim = 0.8, activity_indiff = 0.7,
w_activity = 0.2) {
list(
crit_activity_profile(weight = w_activity, indifference = activity_indiff,
similarity = activity_sim, veto = 0.4),
crit_edit_distance(weight = 0.2, similarity = 2, indifference = 3,
veto = 6),
crit_nominal("status", weight = 0.3),
crit_nominal("satisfaction", weight = 0.3)
)
}We compare clusterings with the Rand index (the fraction of case pairs that two partitions agree to keep together or apart):
rand_index <- function(a, b) {
agree <- 0L; n <- length(a)
for (i in seq_len(n - 1L)) for (j in (i + 1L):n) {
agree <- agree + ((a[i] == a[j]) == (b[i] == b[j]))
}
agree / choose(n, 2)
}
baseline <- cluster_traces(outrank_similarity(traces, criteria()),
k = 4, seed = 42)$membershipsFixed vs quantile thresholds
A threshold can be a fixed number or a quantile of the criterion’s
own value distribution, written as_quantile(p). Quantiles
adapt to the data, which is useful when you do not have a natural
scale.
crit_fixed <- crit_activity_profile(0.2, indifference = 0.7, similarity = 0.8)
crit_quantile <- crit_activity_profile(0.2, indifference = as_quantile(0.5),
similarity = as_quantile(0.8))
crit_quantile
#> <criterion 'activity_profile'>: direction = similarity, weight = 0.2
#> indifference = as_quantile(0.5), similarity = as_quantile(0.8), veto = noneThreshold sensitivity
Sweep the activity-similarity threshold and measure both the average credibility and the agreement of the resulting clustering with the baseline.
grid <- seq(0.75, 0.95, by = 0.05) # kept above the indifference of 0.70
sens <- t(vapply(grid, function(s) {
sim <- outrank_similarity(traces, criteria(activity_sim = s))
memb <- cluster_traces(sim, k = 4, seed = 42)$memberships
c(mean_S = mean(sim$S[upper.tri(sim$S)]),
rand = rand_index(memb, baseline))
}, numeric(2)))
data.frame(similarity = grid, sens)
#> similarity mean_S rand.1
#> 1 0.75 0.4959126 0.9633333
#> 2 0.80 0.4885674 1.0000000
#> 3 0.85 0.4765922 1.0000000
#> 4 0.90 0.4643035 1.0000000
#> 5 0.95 0.4566253 1.0000000The Rand index stays high across the sweep: the four-cluster solution is not an artefact of one threshold choice.
Weight sensitivity
Do the same for the weight of the activities criterion, from negligible to dominant (weights are renormalised internally).
weights <- c(0.05, 0.2, 0.5, 1)
w_sens <- vapply(weights, function(w) {
sim <- suppressMessages(outrank_similarity(traces,
criteria(w_activity = w)))
rand_index(cluster_traces(sim, k = 4, seed = 42)$memberships, baseline)
}, numeric(1))
data.frame(w_activity = weights, rand = w_sens)
#> w_activity rand
#> 1 0.05 0.9633333
#> 2 0.20 1.0000000
#> 3 0.50 0.8666667
#> 4 1.00 0.8666667Choosing k
eigengap() guides k from the spectrum of
the normalized Laplacian; the gap after the k-th eigenvalue marks a
natural cut.
sim <- outrank_similarity(traces, criteria())
gaps <- eigengap(sim, k_max = 8)
gaps[which.max(gaps$gap), ]
#> index eigenvalue gap
#> 2 2 0.3620242 0.5170718Pair the diagnostic with a validity index across candidate
k when is available:
if (requireNamespace("clValid", quietly = TRUE)) {
t(vapply(2:6, function(k) {
cl <- cluster_traces(sim, k = k, seed = 42)
c(k = k, validate_clusters(cl))
}, numeric(3)))
}
#> k connectivity dunn
#> [1,] 2 1.317857 0.3881421
#> [2,] 3 9.033730 0.4285714
#> [3,] 4 20.276190 0.4891980
#> [4,] 5 25.589683 0.4000000
#> [5,] 6 29.134127 0.0000000
